Product Overview
Mimaki CJV150 Series high-speed cut-and-print devices deliver an amazing array of applications in a light production environment. The CJ150Series is a highly versatile printer and cutter that can employ eco-solvent or dye sublimation inks to complete a variety of different application requirements. Eco-solvent inks come in a variety of colors including silver, white, light black and orange while dye sublimation inks come in six colors including light blue and light magenta. Plus, advanced printing technologies combined with precision cutting capabilities enables delivery of complete campaigns that include signs, posters, banners, labels, decals and even T-shirt transfers. Even ink drying is achieved with the intelligent 3-way heating technologies of the Mimaki printing units.
The CJV150-75 is a 32-inch printer with the ability to print eco-solvent or dye-sublimation, and economical 2-liter bulk ink systems are available for those long jobs. Each unit comes pre-bundled with RasterLink RIP software and Flexi Software to make sure your business is set up for success.
The Basic Bundle also includes one of our versatile vinyls, PrismJET 203 Glossy Vinyl. Not only is this bundled with products to get you up and running with your CJV150 unit. We have bundled in 1 year of Mimaki Parts and Phone Support to ensure you have help when you need it and an Onsite Printer Installation and Training is added to this bundle as well.
*Super Solvent Ink is for commercial and industrial use only and requires ventilation. It cannot be used in a home or office.
Features:
- Available in 32 inch, 43 inch, 54 inch, and 64 inch sizes
- Print speeds up to 605 Sq. Ft/Hr
- Choice of eco-solvent ink or dye-sublimation ink sets
- Eco-solvent: 8 color options including silver, white, orange and light black inks
- Dye-sublimation: 6 color options including light blue and light magenta inks
- Optional economical 2-liter bulk ink system for long running jobs
- Even ink drying with three-way intelligent heater
- Incorporates Mimaki’s proprietary technologies to optimize use of standard and specialty colors
- RIP software RasterLink6 included
- Maximum print area: 31.5 inches
- Maximum media width: 31.9 inches
Mimaki CJV150-75 Series Basic Starter Package Contents:
- Mimaki CJV150-75 Hybrid Print and Cutter
- Ink Starter Kit - Customers Choice
- RasterLink RIP Software
- Flexi Software
- 1 Year Mimaki Parts & Phone Support
- One Site Installation & Training
- 30-inch Roll of PrismJET 203 Glossy Vinyl
Mimaki CJV150-75 Plus Specifications
| Print Method | One On-demand Piezo Head |
| Maximum Resolution | 1440 dpi |
| Maximum Print Speed | 432.7 SqFt/Hr (4-Color Mode) |
| Printing Width | 31.9 in (800 mm) |
| Media Width | Maximum 31.9 in (810 mm) |
| Media Thickness | Maximum 0.04 in (1 mm) |
| Media Roll Weight | Maximum 88.2 lbs (40.0 kg) |
| Ink type | Mimaki - SS21, ES3, Sb53, Sb54 |
| Color configuration | Cyan, Magenta, Yellow, Black, Light Cyan, Light Magenta, Light Black, Orange, White, Silver. Dye-Sublimation ONLY Deep Black |
| Cutting Speed | 30cm/sec |
| Cutting Force | Maximum 450 |
| Blade Types | Eccentric cutter, Blade for small character, Blade for reflective sheet, Blade for fluorescent sheet, Blade for PVC with low-pressure, Ball point pen |
| Connectivity | USB 2.0 Hi-speed (Ethernet 100 BASE-T for E-mail notification function) |
| Power Supply | CJV150-75: Single-phase (AC 100–120V / AC 220–240V) |
| Power Consumption | 100V:1.44 kVA × 1 or less / 200V: 1.92 kVA × 1 or less |
| Dimensions | 77 in x 28 in x 55 in (195.6 mm x 71.1 mm x 139.7 mm) |
| Weight | 278 lbs. (126 kg) |
| Shipping Dimensions | 89 in x 30 in x 42 in |
| Shipping Weight | 397 lbs |
| Shipping Crate/Pallet | Shipped in crate on top of pallet |
| Environment: operating ♠ | Temperature: 68° – 86° F (20-30° C) |
| Humidity: 35–65 % RH (Non condensing) | |
| Bundled software | RIP software RasterLink6 included |
| Warranty | One Year Trouble-free Warranty |
| Support | One year complimentary Gold Support |
PrismJET 203 Specifications:
- Color | White
- Finish | Gloss
- Roll Size | 30-inch x 50-yds
- Thickness | 3-mil, blended polymeric PVC film
- Weight | 15lbs
The application’s are endless with the CJV150 series printer/cutters, from banners to vinyl decals to HTV prints for garment decoration. Depending on the type of business set up you have or are wanting to get started with you can rest assured that Mimaki CJV150 units can fit all of your needs with this affordable bundle.
Common Applications:
- Banners
- Decals
- Window Graphics
- Car Wraps/Graphics
- HTV Transfers
- Art Reproduction
PrismJET 203 Applications:
- Indoor and outdoor graphics and signage
- Conforms well to flat surfaces and simple curves
- Building Signs
- Window Signage
- Exterior Signage
- POP Retail Graphics
- Decals
- Nameplates
