Product Overview
The CJV300 Basic Series will provide the end user with endless high-speed for all your printing and cutting needs. Advanced technologies in printing allow for more vibrant reds and oranges with eco-solvent inks including: silver, white, orange, and light black. Precise cutting capabilities enable this hybrid to offer a wide range of applications including signs, posters, banners, labels, decals, and even t-shirt transfers. Dye-sublimation inks are also available for the CJV300 Basic Series. Each unit comes pre-bundled with RasterLink RIP software and Flexi Software to make sure your business is set up for success.
The CJV300-130 is a 54-inch printer with the ability to print eco-solvent or dye-sublimation, and economical 2-liter bulk ink systems are available for those long jobs. The Basic Bundle includes one of our versatile vinyls that can be used in a number of applications, PrismJET 203.
Not only is this bundled with products to get you up and running with your CJV300 unit. We have bundled in 1 year of Mimaki Parts and Phone Support to ensure you have help when you need it and an Onsite Printer Installation and Training is added to this bundle as well.
*Super Solvent Ink is for commercial and industrial use only and requires ventilation. It cannot be used in a home or office.
Features:
- 54-inches
- Print speeds up to 1,140 Sq. Ft/Hr
- Choice of eco-solvent ink or dye-sublimation ink sets
- Eco-solvent: 10 color options including silver, white, orange and light black inks
- Dye-sublimation: 6 color options including light blue and light magenta inks
- ID cut function for automation and unattended operation
- Optional economical 2-liter bulk ink system for long running jobs
- Even ink drying with three-way intelligent heater
- Reusable Mimaki Eco-Cartridge on SS21, BS3 and BS4 eco-solvent inks
- Incorporates Mimaki’s proprietary technologies to optimize use of standard and specialty colors
- Automatic media take-up reel
- USB/Ethernet connectivity
- RIP software RasterLink6 included
- Maximum print area: 53.6 inches
- Maximum media width: 54 inches
Content:
- MIMAKI CJV300-130 Plus 54-inch Printer-Cutter
- Mimaki Edition FlexiDESIGNER and RasterLINK RIP software
- 54-inch x 50-yard Roll of PrismJET 203 glossy calendared print vinyl
- On-site setup and training
- One year of Complimentary Gold Support
- 1-year on-site warranty
PrismJET 203 Specifications:
- Color | White
- Finish | Gloss
- Roll Size | 54-inch x 50-yds
- Thickness | 3-mil, blended polymeric PVC film
Ink Bundles & Pricing
- +$606 | 4 Color Eco-Solvent CMYK (440ml)
- +$1166 | 6 Color Eco-Solvent CMYKLcLm (440ml)
- +$1136 | 7 Color Eco-Solvent CMYKLcLmW (440ml)
- +$1304 | 4 Color Super-Solvent* CMYK (600ml)
- +$1294 | 7 Color Super-Solvent* CMYKLcLmW (600ml)
- +$1294 | 7 Color Super-Solvent* CMYKLkOrW (600ml)
- +$1304 | 8 Color Super-Solvent* CMYKLcLmLkOr (600ml)
- +$5231 | 4 Color Super-Solvent* CMYK (2L)
- +$4601 | 7 Color Super-Solvent* CMYKLcLmW (2L)
- +$4601 | 7 Color Super-Solvent* CMYKLkOrW (2L)
- +$5231 | 8 Color Super-Solvent* CMYKLcLmLkOr (2L)
Mimaki CJV300-130 Plus Specifications
| Print Method | Two On-demand Piezo Heads in a Staggered Array |
| Maximum Resolution | 1440 dpi |
| Maximum Print Speed | 991.4 SqFt/Hr |
| Printing Width | 53.6 in (1,361 mm) |
| Media Width | Maximum 54 in (1,371 mm) |
| Media Thickness | Maximum 0.04 in (1 mm) |
| Media Roll Weight | Maximum 99 lbs. (45 kg) |
| Ink type | Mimaki - SS21, ES3, Sb54 |
| Color configuration | Cyan, Magenta, Yellow, Black, Light Cyan, Light Magenta, Light Black, Orange White, & Silver |
| Cutting Speed | 11.8 in/sec (30 cm/sec) |
| Cutting Force | Maximum 450 |
| Blade Types | Eccentric cutter, Blade for small character, Blade for reflective sheet, Blade for fluorescent sheet, Blade for PVC with low-pressure, Ball point pen |
| Connectivity | Ethernet, USB 2.0 |
| Power Supply | Single phase (AC100-120 / 200-240V±10%, 50/60Hz±1Hz) x2 |
| Power Consumption | AC100V: 1.44kW or less x2 | AC200V: 1.92kW or less x2 |
| Dimensions | 99 in x 28 in x 55 in (251.5 cm x 71.1 cm x 139.7 cm) |
| Weight | 368 lbs. (167 kg) |
| Shipping Dimensions | 105 in x 30 in x 41 in |
| Shipping Weight | 496 lbs |
| Shipping Crate/Pallet | Shipped in crate on top of pallet. *Commercial lift-gate delivery may be required. |
| Environment: operating ♠ | Temperature: 68° – 86° F (20-30° C) |
| Humidity: 35–65 % RH (Non condensing) | |
| Bundled software | RIP software RasterLink6 included |
| Warranty | One Year Trouble-free Warranty |
| Support | One year complimentary Gold Support. On site set up & training is provided (included as part of $3000 installation fee). |
The applications are endless with the CJV300 series printer|cutters, from banners to vinyl decals to HTV prints for garment decoration. Depending on the type of business set up you have or are wanting to get started with you can rest assured that Mimaki CJV300 units can fit all of your needs with this affordable bundle.
Common Applications:
- Banners
- Decals
- Window Graphics
- Car Wraps/Graphics
- HTV Transfers
- Art Reproduction
PrismJET 203 Applications:
- Indoor and outdoor graphics and signage
- Conforms well to flat surfaces and simple curves
- Building Signs
- Window Signage
- Exterior Signage
- POP Retail Graphics
- Decals
- Nameplates
